Features
• 5 year warranty on parts
• Designed for vertical upflow or downflow and horizontal left or right installations
• All aluminum coil (aluminum fins bonded to internally grooved aluminum tubing)
• Coils undergo extensive factory leak testing
• Drain pan made of high grade, heat resistant, corrosion free material
• Coil design maximizes performance while minimizing height requirements
• Bi-directional airflow allows unit to be installed in any position
• Drain pan design maximizes flexibility and condensate removal
• For use with gas and oil furnaces
Unit Specifications
Dimensions: H23 3/16" x W14" x D21 11/16"
Liquid Line Valve Connection: 3/8" inside diameter
Suction Line Valve Connection: 3/4" inside diameter
Capacity: 18,000-24,000 BTU/HR
