Features
• Multi-position design: upflow, horizontal right standard; field convertible to horizontal left or downflow
• 10 year warranty on parts & compressor (registration required)
• Inverter Compressor (33%-110% Speed), Modulation in 1% Increments
• Fully insulated cabinet design
• Noise reducing compressor sound blanket
• All aluminum evaporator coil for superior corrosion resistance
• Quiet & efficient multi-speed PSC indoor blower motor
• Factory installed TXV metering
• Crankcase Heater Standard
• Pre-charged with R-410A refrigerant
• Integrated filter rack with tool-less door access
• Condensate drain pan is polymer with UVC inhibitor
• Multiple System Protection: High pressure switch & low pressure transducer, compressor liquid return protection, compressor high or low compression ratio protection, compressor high temperature protection, high/low voltage protection & over current protection, IPM & electronic control board high temperature protection
Unit Specifications
Condenser Dimensions: W29 1/8" x D29 1/8" x H33 3/16"
Air Handler Dimensions: W22" x D24" x H54 1/2"
EER2: 9.8
HSPF2: 8.0
Volts: 208/230
Phase: 1
Hertz: 60
Liquid Line Valve Connection: 3/8" outside diameter
Suction Line Valve Connection: 7/8" outside diameter
Condenser Specification Sheet
Air Handler Specification Sheet
