5 Ton Ameristar by Trane 14.3 SEER2 R410A Single Stage Heat Pump Split System



Condenser: M4HP5060E1000A
Air Handler: M4AH4E61B1C00A


The Ameristar line of heating and cooling products is made by Ingersoll Rand which is part of the Trane and American Standard family.

•  10 year warranty on parts
•  10 year warranty on compressor
•  Single stage scroll compressor for higher efficiency & increased reliability
•  Quiet & efficient multi-speed PSC indoor blower motor
•  Multi-position design for upflow, downflow, horizontal left or horizontal right installations
•  Painted, galvanized steel cabinets resist rust & stand up to weather with 500 hour salt spray
•  All aluminum factory-installed evaporator coil
•  Insulated air handler blower & coil compartments
•  Condenser pre-charged with R410A refrigerant
•  Suitable for use in manufactured & mobile homes
•  Integrated Horizontal Drain pans and metal Vertical Drain

Condenser Dimensions:  H33 3/16" x W29 1/8" x D29 1/8"
Air Handler Dimensions:  H54 1/2" x W 22" x D24
Volts:  208/240
Phase:  1
Hertz: 60
EER:  11.7
HSPF:  7.5
Liquid Line Valve Connection:  3/8" outside diameter
Suction Line Valve Connection:  7/8" outside diameter

Condenser Specification Sheets
Air Handler Specification Sheets

Additional information

Indoor Unit Air Flow

, ,



Cooling Efficiency

Cooling Capacity
