Features
• Energy Star Certified
• 10 year warranty on parts (registration required)
• Lifetime warranty on compressor (registration required)
• Quiet & efficient variable speed ECM indoor blower motor
• High efficiency two-stage scroll compressor
• Two speed quiet condenser fan motor
• Designed for vertical upflow, downflow & horizontal applications
• All aluminum factory-installed evaporator coil
• Insulated air handler blower compartment optimizes thermal & sound performance
• High-density foam compressor sound reducing blanket
• Tool-less filter access on indoor air handler
• Factory installed expansion valve for indoor coil
• Integrated communicating ComfortBridge™ technology continuously monitors system performance for customized indoor comfort
• Condenser pre-charged with R-410A refrigerant
• Factory installed bi-flow filter drier, compressor crankcase heater & high-capacity muffler
• Improved humidity & comfort control
• Factory installed coil & ambient temperature sensors
Specifications
Condenser Dimensions: W35 1/2" x D35 1/2" x H40"
Air Handler Dimensions: W21" x D21" x H53 7/16"
Volts: 208/240
Phase: 1
Hertz: 60
EER: 13.0
HSPF: 9.0
Liquid Line Valve Connection: 3/8" outside diameter
Suction Line Valve Connection: 7/8" outside diameter
Condenser Specification Sheets
Air Handler Specification Sheets
Additional information
Indoor Unit Air Flow | Upflow (Top Discharge), Downflow (Bottom Discharge), Horizontal (Side Discharge) |
---|---|
Brand | |
Energy Star Certified | Yes |
Model Number | GSZC160361, AVPTC37C14 |
Refrigerant | |
Cooling Efficiency | |
Subtitle | Electric Split, Heat & Air (AC) System, GSZC16 & AVPTC, Energy Star Certified |
Cooling Capacity |
