Features
• Condenser is Energy Star Certified
• 10 year warranty on parts & compressor (registration required)
• High efficiency single stage scroll compressor
• Direct drive multi-speed PSC indoor motor
• All aluminum evaporator coil
• High and low pressure switches
• Designed for upflow, downflow, horizontal left and horizontal right installations
• Factory installed compressor crankcase heater
• Condenser pre-charged with R-410A refrigerant
• Insulated air handler cabinet
• Factory installed high capacity muffler
• Aluminum tube condensing coil with aluminum fins
• Factory installed bi-flow liquid line filter drier
• Tool-less filter access accommodates standard size filters
• Factory installed suction line accumulator
• Condenser applicable for ground-level or rooftop mount
• Thermostatic expansion valve (TXV) included (field installation required)

Specifications
Condenser Dimensions:  H39 3/4" x W35 1/2" x D35 1/2"
Air Handler Dimensions:  H53 7/16" x W21" x D21"
Volts:  208/240
Phase:  1
Hertz: 60
EER:  11.5
HSPF:  8.2
Liquid Line Valve Connection:  3/8" outside diameter
Suction Line Valve Connection:  7/8" outside diameter
